Common Data Service Entity Creation – Power BI

One comment

In this tutorial, we’ll talk about how to create a Common Data Service Entity. Creating this is essential when building a common data service that’s needed in building a business process flow.

Common Data Service (CDS) is a data storage system, like a database. It stores data in the form of tables, also known as Entities.

Keep in mind that we need to create a new environment first with permission for us to create an entity. We discussed this in a separate tutorial. Again, make sure that we’re working in a new environment. We can see our current environment here.

common data service entity

Creating A Common Data Service Entity

Since we’ve already created an environment beforehand, we can now proceed to creating our Common Data Service entity. First, click the Entities under Data

common data service entity

Make sure we’re on the Power Apps Entities page.

common data service entity

Then, click on the New entity option.

common data service entity

For this example, let’s set the Display name to NewEmployee. After typing the NewEmployee as our Display name, the Plural display name and Name textboxes values are generated automatically.

common data service entity

For the Display name under the Primary Name Field, let’s set it to EmployeeID. Again, the Name textbox value under it is generated automatically as well.

common data service entity

Then, click the Done button.

common data service entity

After that, it’s now provisioning our entity on the background as stated. It also listed an EmployeeID field.

common data service entity

After successfully provisioning our Common Data Service entity, a lot of other fields are also added. When this database was made, all the created tables must have a certain amount of columns. That’s because we’ve set up the database in a way where no matter what table or entity gets created, these additional columns are always added as well.

common data service entity

Adding Basic Fields To Common Data Service Entity

Let’s now add our own columns as well. These are the fields that we’d want to collect when we’re onboarding a new employee in our business process flow.

First, let’s click the Add field.

common data service entity

Then, set the Display name to FirstName. The Name textbox value will also be automatically generated.

common data service entity

After that, set the Data type to Text.

common data service entity

Let’s make this field Required. This means that the users are required to enter their first name.

common data service entity

Then click the Done button.

common data service entity

We can now see the FirstName field in the list.

common data service entity

Let’s add another field for the last name. To do that, click the Add field again.

Let’s set the Display name to LastName, set the Data type to Text, make it Required, and click the Done button.

Next is to add a phone number field. Name it as PhoneNumber, set the Data type to Phone, and make it an Optional field, then click the Done button.

Let’s also add a field for the employee’s date of birth. Name it as DOB. The Data type should be Date Only. Make this field Required and click the Done button.

Next is to add an employee position field. Let’s name this as Position

To make this field more interesting, let’s set the Data type to Multi Select Option Set. This will allow us to choose from multiple options.

Then, click on the Option set and select New option set

After that, let’s add Developer and Tester as the two options.

Then, click the Save button.

Let’s make this field  Required as well because we want to know if the employee is a developer or a tester.  Then click the Done button.

Creating Fields For Additional Information

Let’s also add a field about the details of their position. For example, if they’re a developer, we’d want to know the environment they’re working on. So, let’s name this as DeveloperEnvironment. The Data type should be Text. Let’s set this field as Optional because if they’re a Tester, they don’t need this field. Then, click the Done button.

Now, if they’re a Tester, they need to have a product to test. So, let’s add a new field and name it as TesterProduct. The Data type should be Text, and it’s Optional because the Developers don’t need this. Then, click Done

Let’s also add a field for their reporting manager. Name this as ReportingManager and set the Data type to Text. Make this field Required and click the Done button.

Finally, let’s add a field for their starting pay. Name this field as StartingPay and set the Data type to Whole Number. Make the field Required and click the Done button.

After adding all those fields or columns, we can see that they’re listed here and bolded.

Lastly, click the Save Entity button to finalize these changes.

Conclusion

To sum up, we’re able to understand the usage and importance of a Common Data Service entity. CDS is a free database service in Power Apps that uses entities to store data.

We’re also able to create an entity in our environment and learned how simple it is to add fields for our entity. By finalizing your CDS entity first, you can easily start creating business process flows in Power Automate.

All the best,

Henry
